photokina:coverage:gh3

GH3 topic on forum:
http://www.personal-view.com/talks/discussion/4592/official-panasonic-gh3-topic

Panasonic pages about GH3:
http://panasonic.net/avc/lumix/systemcamera/gms/gh3/index.html

Direct manuals links


Other pages about GH3

Specifications

Comparison

Specs

  • Effective Megapixels - 16.1 Megapixels (17.20 total)
  • Live MOS/17.3 x 13.0 mm (in 4:3 aspect ratio), not multi aspect
  • LSI - Venus Engine VII FHD
  • 200 - 12800 ISO
  • WB Presets - 5
  • 1080 60p/30p (NTSC) 50p/25p(PAL) 24p(12p,50p, etc also present)
  • Same for 720p (60p/30p for NTSC and 50p/25p for PAL), no high speed modes
  • AVCHD 2.0 normal bitrate options
  • 50Mbps bitrate and 72Mbps Intra for 24p (and variations)
  • SD, SDHC, SDXC cards compatible (UHS-I)
  • 3.0” 615k OLED Monitor with capacitive touch control
  • EVF - OLED 1.74Mpix
  • Shutter Speeds - from 60 sec to 1/4000 sec
  • Flash modes - Auto, Auto/Red-eye Reduction (when iA, iA+), Forced On, Forced On/Red-eye Reduction, Slow Sync., Slow Sync./Red-eye Reduction
  • Continuous Shooting Speed - 6 fps (20fps low res)
  • Weather Proof - yes
  • WB - Auto, Daylight, Cloudy, Shade, Incandescent, Flash, White Set 1, 2, Color temperature setting
  • USB 2.0 (sic!)
  • 3.5mm mic and headphone jacks
  • Remote - optional DMW_RSL1
  • Battery - Li-ion Battery Pack (7.2V, 1860mAh), *new*
  • Dimensions - 132.9 x 93.4 x 82.0mm / 5.23 x 3.68 x 3.23 in
  • Weight - 550g / 16.58 oz (Body only)
  • Price - $1299 (body only!)
  • Available from - November 2012

Photo and video samples

Video Compression Modes

MOV

  • 1,920 x 1,080, 30p (sensor output is 30p, 72Mbps (ALL-Intra))
  • 1,920 x 1,080, 24p (sensor output is 24p, 72Mbps (ALL-Intra))
  • 1,280 x 720, 60p (sensor output is 60p, 72Mbps (ALL-Intra))
  • 1,920 x 1,080, 60p (sensor output is 60p, 50Mbps (IPB))
  • 1,920 x 1,080, 30p (sensor output is 30p, 50Mbps (IPB))
  • 1,920 x 1,080, 24p (sensor output is 24p, 50Mbps (IPB))
  • 1,920 x 1,080, 25p (sensor output is 25p, 72Mbps (ALL-Intra))
  • 1,920 x 1,080, 24p (sensor output is 24p, 72Mbps (ALL-Intra))
  • 1,280 x 720, 50p (sensor output is 50p, 72Mbps (ALL-Intra))
  • 1,920 x 1,080, 50p (sensor output is 50p, 50Mbps (IPB))
  • 1,920 x 1,080, 25p (sensor output is 25p, 50Mbps (IPB))
  • 1,920 x 1,080, 24p (sensor output is 24p, 50Mbps (IPB))

MP4

  • [Full HD] 1,920 x 1,080, 30fps (sensor output is 30p, 20Mbps)
  • [Full HD] 1,920 x 1,080, 25fps (sensor output is 25p, 20Mbps)
  • [HD] 1,280 x 720, 30fps (sensor output is 30p, 10Mbps)
  • [HD] 1,280 x 720, 25fps (sensor output is 25p, 10Mbps)
  • [VGA] 640 x 480, 30fps (sensor output is 30p, 4Mbps)
  • [VGA] 640 x 480, 25fps (sensor output is 25p, 4Mbps)

AVCHD

  • 1,920 x 1,080, 60p (sensor output is 60p, 28Mbps)
  • 1,920 x 1,080, 50p (sensor output is 50p, 28Mbps)
  • 1,920 x 1,080, 24p (sensor output is 24p, 24Mbps)
  • 1,920 x 1,080, 60i (sensor output is 30p, 24Mbps)
  • 1,920 x 1,080, 60i (sensor output is 60p, 17Mbps)
  • 1,920 x 1,080, 24p (sensor output is 24p, 24Mbps)
  • 1,920 x 1,080, 50i (sensor output is 25p, 24Mbps)
  • 1,920 x 1,080, 50i (sensor output is 50p, 17Mbps)

Video Compression Research

Description

The body has been engineered to incorporate a 16.05-megapixel Digital Live MOS Sensor, a 4-CPU Venus Engine, and a newly designed low-pass filter. The creative expression made possible by these innovations, render even the finest textures in intricate detail, breaking new ground in photographic realism. The new model also features Contrast AF with a high level of response. And its magnesium alloy frame is tightly sealed to resist splashes and dust, making the DMC-GH3 rugged enough to withstand the rigors of professional use.

Features:

  • 16.05-megapixel Digital Live MOS Sensor
  • HDR (High Dynamic Range)
  • Double OLED Display
  • Splash/Dustproof Design
  • Full-HD Progressive
  • Smartphone or Tablet Linking

In addition to supporting a wide range of recording formats, the DMC-GH3 features a special heat-dispersing design for extended high-quality recording. Its specifications match those of many professional cameras, ensuring that it meets the demands of video field work. The LUMIX GH3 was designed from the ground up to provide seamless multi-media performance for both stills and videos. It may well be the world's first camera to please professional photographers by offering them the best of both.

The DMC-GH3 features a 16.05-megapixel Digital Live MOS Sensor with a level of sensitivity that produces flowing gradation from shadows to highlights. High resolution and a wide dynamic range create truly stunning images that look like you could reach out and touch them. High-sensitivity ISO 12800 (extended: ISO 25600) and extensive noise reduction give you remarkable images even in dim lighting.

In the DMC-GH3's Contrast AF system, the image sensor doubles as the AF sensor to resist any mechanical margin of error. Compared with Phase Difference AF, the focusing is precise even at small F-numbers. A faster sensor and engine also achieve a higher focus detection speed than most traditional DSLR models.

The DMC-GH3 gives you 1920 x 1080 60p [NTSC] / 50p [PAL] Full-HD recording. Progressive scanning records every frame, so the amount of data contained is twice that of interlace scanning, and the images have extremely high definition.

The Wi-Fi function lets you use a smartphone to make settings and press the shutter button remotely, a short distance from the camera. The auto transfer function is handy for automatically backing up photos onto a tablet. This lets you monitor them on the tablet without having to upload them to a PC. You can also start timer interval video recordings from a smartphone. And you can use GPS data to simultaneously record the shooting location onto your images.

Available for preorder at

Images



Videos

Extra


Reviews and previews
